Hand-held thermoformer
Rivet Sealer 3000 V2.0 Kit
Heat adapter, RS Perforator and two 100% virgin Teflon™ tips. Perforate, then heat and press at the same time to reset the film's memory. No primer, no tenting.
SGIA Product of the Year · Built by an installer
Seal every rivet. Wrap without the pain.
The Rivet Sealer 3000 is a hand-held thermoformer for rivets. The SE360 is the squeegee built for the human hand. Two tools, designed and built by an installer, for installers.
- Tip temp
- 360–410°F
- Primer
- None needed
- vs torch & brush
- 75–80% faster
Award-winning toolsSGIA Product of the Year · Best of Show
ISA Sign ExpoGraphics of the Americas (GOA)AustraliaCanadaIreland
Shop by category
Everything for the install
The lineup
Two tools. Every install.
Ergonomic squeegee
SE360 Squeegee Evolved
A tapered barrel handle and Thumb Orbit splint the thumb so your four fingers do the work. Quick-eject blades swap in seconds.
0trucks & vehicles wrapped by our founder
0years on the panel
0faster than torch & brush
0heat-forming at the tip
Rivet Sealer 3000
Reset the vinyl's memory. Skip the primer.
Vinyl is manufactured flat with heat, and its molecular memory keeps pulling it back to flat. That's why rivets pop up the next day. Heat and pressure at the same time resets that memory to the shape of the rivet.
Cut-away view
Watch what happens overnight
SE360 Squeegee EvolvedBuilt for the human hand. Not for the shelf.
Every other squeegee is a flat card you pinch with your thumb, thousands of times a day. That compresses the median nerve at the wrist. The SE360 was developed with UK neuroscientist Dr. Martin Lebrough in 2008, and designed from day one to take that load off your hand.
See the difference
What a flat squeegee does to your hand
The base of the thumb is one of the weakest, most overworked joints in the hand. A flat squeegee puts it in charge of the whole job. The SE360 splints the thumb and hands the work to your four fingers.
Illustration for explanation only, not a medical diagnosis.
Surgery is not a quick fix
Carpal tunnel release can take months to recover from. Some patients are left with lasting numbness, a weaker grip or reduced feeling in their fingers. For an installer, feel is everything: the film's tension, a trapped bubble, the edge of a rivet.
Stop straining. Start working in comfort.
Designed to reduce wrist fatigue and median-nerve strain. Learn about carpal tunnel syndrome from the NIH.
The Graffix Tools story
By an installer.
For installers.
3,000+trucks and vehicles wrapped
28years on the panel
I wrapped over 3,000 trucks and vehicles over 28 years. Thousands of rivets, miles of film, and a flat squeegee pinched in my thumb every single day. It gave me carpal tunnel syndrome.
So I designed the tools I wish I'd had from day one: the Rivet Sealer 3000, so no installer has to fight the same rivet twice, and the SE360, built around the human hand so the thumb is splinted and the fingers do the work.
Your hands are your career. Don't learn that the way I did.
Raven · Founder, Graffix Tools
Keep them running
Parts, tips & blades
Every heat tip is machined from 100% virgin Teflon™. Send back used tips and get $2 off your next order for each one.
100% virgin Teflon™
Teflon™ Heat Tips · 4-Pack
Eight sizes, 1/4" to 1" Zeus and Box Truck
$34.95
Choose options
5 blade types
SE360 Blades · 3-Pack
Green, Midnight, Charcoal, Ocean Blue, Gold
$29.95
Choose options
Silver or Gold
Rivet Sealer Adapter
Ported aluminum, with one tip of your choice
$44.95
Choose options
Word from the panel
From the installers
"It's already paid for itself over and over. You guys changed the industry with this tool. Every sign shop should have at least two of these!"
"I bought the Rivet Sealer 3000 in 2008 and I have done over 250 trailers. I wouldn't use anything else!"
"It not only does a better job with the rivets, it also saves us an enormous amount of time."
Read before use
Safety & proper use
The Rivet Sealer works because it gets hot. Respect the heat and it will seal rivets for years.
Warning
Hot surface: burn hazardThe adapter and Teflon™ tip run at 360–410°F and can cause severe burns. Never grab or touch the heat tip or adapter while hot or cooling. Let it cool completely before changing tips, and set it down only on a heat-safe surface.
Caution
Sharp element: puncture hazardPerforator needles can puncture skin. Do not press down on the perforator tip with your thumb. Hold the RS Perforator by its handle.
Notice
Overheating damages filmToo much heat or holding the tip too long can burn, discolor or distort the vinyl. Use a recommended heat gun, press for about one second, and test on a scrap of the same film first.
Notice
No excessive pressureLight, straight-on pressure is all it takes. Forcing the tool can damage the tool tip.
Notice
Do not dropDropping the adapter or perforator can damage the tool tip.
Read first
Refer to the instruction manualRead all warnings and instructions before first use. Keep the manual with the tool.
Distributors & shops
Carry Graffix Tools.
Distributor pricing is available for sign supply houses and wrap shops. Call or email and we'll set you up.
